- General Information
- Manufacturer
- Zebra Technologies Corporation
- Manufacturer Website Address
- http://www.zebra.com/gb/en
- Brand Name
- Zebra
- Product Series
- ZQ600
- Product Type
- Direct Thermal Printer
The ZQ600 Series takes Zebra's popular QLn platform and makes it even better, adding advanced technology and innovative design that drive productivity, ease-of-use and manageability to a new level. The 4-inch ZQ630 RFID helps users save time, reduce errors, print and encode RFID labels and tags on the spot with ease. A large, color display takes the guesswork out of printer status. Advanced battery technology and more battery capacity power every minute of the longest shift. The instant wake-up feature on WiFi or Bluetooth ensures the ZQ630 RFID never sleeps on the job. Plus, the ZQ630 RFID is easy to integrate, manage, setup and secure thanks to Zebra's Link OS® operating system and powerful Print DNA suite of applications, utilities and developer tools.
- Technical Information
- Recommended Use
- Label/Receipt Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 115 mm/s
- Maximum Print Resolution (dpi)
- 203
- Maximum Print Length
- 813 mm
- Maximum Print Width
- 104 mm (4.09")
- Barcode Symbology Supported
- Code 39
- Code 93
- UCC/EAN 128
- Code 128
- Codabar (NW-7)
- Interleaved 2 of 5
- UPC-A
- UPC E with 2 and 5 add on
- EAN-8
- EAN-13
- PDF417
- Micro PDF-417
- Maxi Code
- QR Code
- GS1 DataBar
- Aztec Code
- MSI PLESSEY
- FIM
- POSTNET
- Data Matrix
- TLC 39
- Application/Usage
- Mobile
- Features
- Belt Clip
- Shoulder Strap
- Dust Resistant
- Water Resistant
- Mobile Device Printing
- Yes
- Connectivity Technology
- Wireless
- Print Technology
- Direct Thermal
- Memory
- Standard Memory
- 256 MB
- Network & Communication
- Bluetooth
- Yes
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11a/c
- Near Field Communication (NFC)
- Yes
- Media Types & Handling
- Media Type
- Gap
- Black Mark
- Receipt
- Label
- Die-cut Label
- Tag
- Liner-free Label
- Black Bar
- Media Thickness
- 165.1 µm
- Maximum Roll Diameter
- 66.04 mm
- Maximum Label Width
- 111.76 mm
- Maximum Label Length
- 812.80 mm
- Fonts & Emulation
- Language Emulation
- CPCL
- EPL
- ZPL
- XML
- ZPL II
- Power Description
- Power Source
- Battery
- Battery Information
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Rechargeable
- Yes
- Battery Capacity
- 6800 mAh
- Environmental Conditions
- Operating Temperature
- -20°C - 50°C
- Operating Relative Humidity
- 10% - 90%
- Storage Temperature
- -25°C - 65°C
- Storage Relative Humidity
- 10% - 90%
- Physical Characteristics
- Height
- 82.6 mm
- Width
- 165.1 mm
- Depth
- 186.7 mm
- Weight (Approximate)
- 1.10 kg
- Miscellaneous
- Platform Supported
- iOS
- Android
- PC
- Certifications & Standards
Emissions:
- FCC Part 15
- Subpart B
- EN55022 Class-B
- EN60950
- EN55024
- VCCI class B
Susceptibility:
- EN55024
- EN61000-4-2
- EN61000-4-3
- EN61000-4-4
- EN61000-4-5
Safety:
- CE
- TUV
- CSA
