- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.co.uk
- Brand Name
- Supermicro
- Product Line
- SuperWorkstation
- Product Type
- Server Barebone System
- Warranty
- Limited Warranty
- 1 Year
- Additional Warranty Information
Supermicro provides a three-year warranty for labor and one-year warranty for parts.
- Processor
- Number of Processors Supported
- 1
- Processor Socket
- Socket LGA-4677
- Processor Supported
- Xeon
- 64-bit Processing
- Yes
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- W790
- Memory
- Maximum Memory Supported
- 2 TB
- Memory Technology
- DDR5 SDRAM
- Total Number of Memory Slots
- 16
- Storage
- Supported Storage Drive Interfaces
- Serial ATA III
- PCI Express NVMe
- Supported Storage Drive Types
- HDD
- SSD
- Controllers
- Controller Type
- Serial ATA/600
- NVMe
- Network & Communication
- Ethernet Technology
- 10 Gigabit Ethernet
- Gigabit Ethernet
- I/O Expansions
- Number of Total Expansion Bays
- 6
- Number of External 5.25" Bays
- 2
- Number of 3.5" Bays
- 4
- Total Number of Expansion Slots
- 6
- Number of PCI Express x16 Slots
- 6
- Number of M.2 Interfaces
- 4
- Interfaces/Ports
- Total Number of USB Ports
- 12
- Number of USB 3.2 Gen 1 Ports
- 2
- Number of USB 3.2 Gen 2 Ports
- 4
- USB Type-C (Front)
- Yes
- USB Type-C (Rear)
- Yes
- USB Type-C Detail
- 1 x 3.2 Gen 1 type C, 1 x 3.2 Gen 2x2 type C
- Number of Serial Ports
- 1
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 2
- Number of VGA Ports
- 1
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Installed
- 1
- Maximum Power Supply Wattage
- 2 kW
- Frequency
- 50 Hz
- 60 Hz
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Tower
- Height
- 534.9 mm
- Width
- 222 mm
- Depth
- 573 mm
- Weight (Approximate)
- 9.07 kg
- Miscellaneous
- Package Contents
- SuperWorkstation SYS-551A-T
- 1 x Super X13SWA-TF Motherboard
- 1 x 5U (Full Tower) Chassis
- 4 x 7pin SATA (STR to STR), 57.5cm, Flat, PBF
- 1 x PWCD,US,NEMA 5-15P TO IEC60320 C19, 6FT, 14AWG, 15A/125V
- 1 x STD I/O Shield for X13SWA-TF with EMI Gasket & Black Mylar
- 1 x PS2 2000W Multi-output PLATINUM power supply,RoHS
- 1 x License key for enabling OOB BIOS management
- 4 x M.2 Passive Heat Sink for Both 2280 & 22110 M.2 Type
- 2 x 120x120x25 mm, 2.2K RPM, Cooling Fan for GS7 Project,RoHS
- 1 x 120x120x25 mm, 6.4K RPM, Optional Fan for GS7 Project
