- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.co.uk
- Brand Name
- Supermicro
- Product Line
- SuperServer
- Packaged Quantity
- 1
- Product Type
- Server Barebone System
- Processor
- Number of Processors Supported
- 2
- Processor Socket
- Socket LGA-4677
- Processor Supported
- Xeon Platinum
- Xeon Gold
- Xeon Silver
- Xeon Bronze
- 64-bit Processing
- Yes
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C741
- Memory
- Maximum Memory Supported
- 4 TB
- Memory Technology
- DDR4 SDRAM
- Memory Standard
- DDR5-5600/PC5-44800
- Total Number of Memory Slots
- 16.0
- Storage
- Supported Storage Drive Interfaces
- Serial ATA
- SAS
- Supported Storage Drive Types
- SSD
- HDD
- Controllers
- Controller Type
- Serial ATA
- Serial Attached SCSI (SAS)
- NVMe
- Network & Communication
- Ethernet Technology
- 10 Gigabit Ethernet
- I/O Expansions
- Number of Total Expansion Bays
- 18
- Total Number of Expansion Slots
- 16.0
- Number of PCI Slots
- 6
- Number of PCI Express x8 Slots
- 2
- Number of PCI Express x16 Slots
- 4
- Number of M.2 Interfaces
- 2
- Interfaces/Ports
- Total Number of USB Ports
- 4
- Number of USB 3.0 Ports
- 4
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 3
- Number of VGA Ports
- 1
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Installed
- 2
- Maximum Power Supply Wattage
- 1.20 kW
- Frequency
- 50 Hz
- 60 Hz
- Physical Characteristics
- Color Family
- Silver
- Product Color
- Silver
- Form Factor
- Rack-mountable
- Rack Height
- 3U
- Height
- 132.1 mm
- Width
- 436.9 mm
- Depth
- 647.7 mm
