- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.co.uk
- Brand Name
- Supermicro
- Product Line
- IoT SuperServer
- Product Type
- Server Barebone System
- Warranty
- Limited Warranty
- 1 Year
- Additional Warranty Information
Supermicro provides a three-year warranty for labor and one-year warranty for parts.
- Processor
- Number of Processors Supported
- 1
- Number of Processors Installed
- 1
- Processor Socket
- Socket BGA-1744
- Processor Type
- Core i5
- Processor Generation
- 12th Gen
- Processor Model
- i5-1245UE
- Processor Core
- Deca-core (10 Core)
- 64-bit Processing
- Yes
- Chipset
- Chipset Manufacturer
- Intel
- Memory
- Maximum Memory Supported
- 64 GB
- Memory Technology
- DDR5 SDRAM
- Total Number of Memory Slots
- 2
- Storage
- Supported Storage Drive Interfaces
- PCI Express 4.0 x4
- Serial ATA
- Supported Storage Drive Types
- SSD
- Controllers
- Controller Type
- NVMe
- Serial ATA
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- I/O Expansions
- Total Number of Expansion Slots
- 1
- Number of PCI Express x4 Slots
- 1
- Number of M.2 Interfaces
- 2
- Interfaces/Ports
- HDMI
- Yes
- Total Number of USB Ports
- 8
- Number of USB 3.2 Gen 1 Ports
- 2
- USB Type-C (Front)
- Yes
- USB Type-C Detail
- 2 USB 3.2 Gen1 Type-C ports
- Number of Serial Ports
- 4
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 2
- Mini DisplayPort
- Yes
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Installed
- 1
- Maximum Power Supply Wattage
- 84 W
- Thermal Design Power
- 15 W
- Frequency
- 47 Hz
- 63 Hz
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Box PC
- Height
- 43.9 mm
- Width
- 195.1 mm
- Depth
- 150.9 mm
- Weight (Approximate)
- 979.8 g
- Miscellaneous
- Package Contents
- IoT SuperServer SYS-E100-13AD-E
- 1 x Super X13SAN-E-WOHS Motherboard
- 1 x Fanless Embedded Chassis
- 1 x PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,18AWG,RoHS/REACH
- 2 x USB 2.0,INT-EXT,2 PORT,TYPE-A-2X5/P2.00, 18CM
- 1 x SERIAL, DB9F TO 2X5F/P2.00,INT TO EXT,FLAT, 30CM, 28AWG
- 1 x 2x LED (green, orange) to 8P/F/P2.00 + push button switch, 32CM, 26AWG
- 1 x 84W Lockable AC to DC power adapter w/o power cord - EN62368
- 1 x for X13SAN in system
- 1 x E100-13AD-H/E/L/C Quick Reference Guide
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
