- General Information
- Manufacturer
- Newland
- Manufacturer Website Address
- http://www.newland-id.com
- Brand Name
- Newland
- Product Type
- Grip
- Physical Characteristics
- Height
- 165 mm
- Width
- 160 mm
- Depth
- 82 mm
- Weight (Approximate)
- 230 g
- Miscellaneous
- Additional Information
Data Capture:
- Illumination: White LED
- Aiming : Laser aiming
- Resolution: 1280x800, monochrome, 30 frame/sec
- Scan Rate: Up to 30f/s seif-adaption
- Depth of Field Code128 (15mil): 75mm-2600mm
- Depth of Field Code128 (100mil): 440mm-9800mm
- Depth of Field DataMatrix (10mil): 190mm-310mm
- Depth of Field DataMatrix (55mil): 105mm-3900mm
- Depth of Field QR Code (10mil): 195mm-250mm
- Depth of Field QR (55mil): 110mm-3700mm
Performance:
- Scan Angle: Pitch 75°, Skew 45°
Physical:
- User Input: Trigger on pistol grip
Environmental
- Operating Temperature: -20°C to 50°C {-4°F to 122°F)
- Storage Temperature: -30°c to 70°c {-22°F to 158°F)
- Humidity: 5% to 95% {non-condensing)
- Electro Static Discharge (E5D}: ±15kV {air discharge}, ±8kV {direct discharge)
- Drop: 1.2m
- IP Rating: IP65
Communication:
- Host Terminal: MT90 Orca III
- Host Connection: 8-pin connector
- Newland EMEA HQ
Suggested industries:
- Logistics
- Transportation
- Warehousing
- Compatibility
Newland MT90 Orca III Mobile Computers
