- General Information
- Manufacturer
- Microchip Technology Inc.
- Manufacturer Website Address
- http://www.microchip.com
- Brand Name
- Microchip
- Product Type
- PoE Injector
Microchip's PD-9501GC is a single-port solution for remote powering of current as well as emerging high-power applications. The PD-9501GC is designed specifically to power IEEE 802.11n and IEEE 802.3bt access points, Pan-Tilt-Zoom (PTZ) and dome cameras, IP videophones, thin clients and other high-power Ethernet end terminals with 60W of power and it is als backwards compatible and safe to use with any IEEE 802.3af/at terminals such as VoIP phones, IP cameras and wireless LAN access points. It can power both existing 10/100Base-T devices and Gigabit devices such as wireless IEEE 802.11n access points. The PD-9501GC provides power on all 4-pairs while being backwards compatible to IEEE 802.3af and IEEE 802.3at powered devices.
- Warranty
- Limited Warranty
- 1 Year
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Maximum Output Voltage
- 55 V DC
- Maximum Input Current
- 1.50 A
- Minimum Frequency
- 50 Hz
- Maximum Frequency
- 60 Hz
- Maximum Output Power
- 60 W
- Interfaces/Ports
- Input Ports
- 1 x Ethernet
- Output Ports
- 1 x RJ-45
- Physical Characteristics
- Height
- 38 mm
- Width
- 62 mm
- Length
- 151 mm
- Weight (Approximate)
- 500 g
- Miscellaneous
- Package Contents
- PD-9501GC Single-Port IEEE802.3bt 60W Gigabit PoE Midspan
- Power Cord
- Certifications & Standards
- IEEE 802.bt Type 3 Compliant
- IEEE 802.3af/at Backward Compatible
- FCC Part 15, Class B
- EN 55032 Class B
- EN 55024
- VCCI
- UL
- IEC
- EN 62368-1
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Country of Origin
- China
