- General Information
- Manufacturer
- HP Inc.
- Manufacturer Website Address
- http://www.hp.com
- Brand Name
- HP
- Product Line
- Ultra
- Product Type
- Docking Station
- Technical Information
- Connectivity Technology
- Wired
- Charging Capability
- Yes
- Device Supported
- Desktop PC
- Mobile Workstation
- Notebook
- Cable Length
- 97.54 cm
- Features
- Security Lock
- Management Features
- PXE Boot
- Wake-on-LAN
- MAC Address Pass-through
- WLAN to LAN Switch
- Number of Displays Supported
- 4
- Screen Mode Supported
- 8K
- 4K UHD
- QHD
- Full HD
- 4K @ 60Hz
- 4K @ 120Hz
- 8K @ 60Hz
- 8K @ 30Hz
- 5K
- 4K @30Hz
- Supported Resolutions
- 7680 x 4320
- 3840 x 2160
- 2560 x 1440
- 1920 x 1080
- 5120 x 2160
- Maximum Data Transfer Rate
- 5 GB/s
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- Interfaces/Ports
- Host Interface
- Thunderbolt 4
- Total Number of USB Ports
- 8
- USB Type-A
- Yes
- Number of USB 3.2 Gen 1 Type-A Ports
- 2
- Number of USB 3.2 Gen 2 Type-A Ports
- 3
- Number of USB Type-A Ports
- 5
- USB Type-C
- Yes
- USB Type-C Detail
- 2 x USB Type-C 3.2 Gen 2 (10 Gbps) port with data and power out (15W), 1 x USB Type-C 3.2 Gen 2 DisplayPort
- Number of USB Type-C Ports
- 3
- Network (RJ-45)
- Yes
- Number of RJ-45 Ports
- 1
- DisplayPort
- Yes
- DisplayPort Version
- 1.4
- Number of Mini DisplayPort
- 2
- HDMI
- Yes
- Number of HDMI Ports
- 1
- HDMI Version
- 2.1
- Thunderbolt
- Yes
- Thunderbolt Ports Quantity
- 1
- Number of Thunderbolt 4 Ports
- 1
- USB Power Delivery
- 180W
- Software
- Operating System Supported
- Windows 10
- ChromeOS
- macOS
- Linux ThinPro 8.0
- Power Description
- Maximum Power Supply Wattage
- 230 W
- Power Source Type
- Power Adapter
- Physical Characteristics
- Height
- 121.2 mm
- Width
- 121.2 mm
- Depth
- 50.5 mm
- Weight (Approximate)
- 800 g
- Miscellaneous
- Package Contents
- Thunderbolt 4 Ultra 180W G6 Dock
- 230W Power Adapter
- Power Cord
- Product Notice
- warranty Card
- Compatibility
HP Products:
- Elite x360 830 13-inch G11 2-in-1 Notebook PC
- EliteBook 830 13-inch G11 Notebook PC
- EliteBook 840 14-inch G11 Notebook PC
- EliteBook 860 16-inch G11 Notebook PC
- ZBook Firefly 14-inch G11 Mobile Workstation PC
- ZBook Firefly 16-inch G11 Mobile Workstation PC
- Elite x360 1040 14-inch G11 2-in-1 Notebook PC
- EliteBook 1040 14-inch G11 Notebook PC
- ZBook Power 16-inch G11 Mobile Workstation PC
- ProBook 440 14-inch G11 Notebook PC
- ProBook 460 16-inch G11 Notebook PC
- EliteBook 630 13.3-inch G11 Notebook PC
- EliteBook 640 14-inch G11 Notebook PC
- EliteBook 660 16-inch G11 Notebook PC
- EliteBook X Flip G1i 14-inch Notebook Next Gen AI PC
- EliteBook X G1i 14-inch Notebook Next Gen AI PC
- EliteBook 8 Flip G1i 13 Notebook PC
- EliteBook 8 G1i 13 Notebook PC
- EliteBook 8 G1i 14 Notebook PC
- EliteBook 8 G1i 16 Notebook PC
- EliteBook 8 G1i 14-inch Notebook Next Gen AI PC
- EliteBook 8 G1i 16-inch Notebook Next Gen AI PC
- ZBook 8 G1i 14-inch Mobile Workstation PC
- ZBook 8 G1i 16-inch Mobile Workstation PC
- ProBook 4 G1i 14 Notebook PC
- ProBook 4 G1i 16-inch Notebook AI PC
- EliteBook 6 G1i 13 Notebook PC
- EliteBook 6 G1i 14 Notebook PC
- EliteBook 6 G1i 16 Notebook PC
- EliteBook X G1a 14-inch Notebook Next Gen AI PC
- ZBook Ultra G1a 14-inch Mobile Workstation PC
- Country of Origin
- China/Thailand
- TAA Compliant
- Yes
