- General Information
- Manufacturer
- ASUS Computer International
- Manufacturer Website Address
- http://uk.asus.com
- Brand Name
- Asus
- Product Line
- TUF Gaming
- Product Type
- Power Supply
Built For The Long Haul
The ASUS TUF Gaming 850W Gold packs military-grade strength, a flagship fan design, and PCB protection for efficient, durable power delivery. The result is a PSU that will reliably fuel your rig for years to come.
Top marks | TUF Components
With military-grade components, including capacitors rated for 105°C operation and up to 170,000 hours' lifespan, the ASUS TUF Gaming 850W Gold empowers you to build in confidence.
2x longer lifespan | Dual Ball Fan Bearings
Exemplary cooling is provided by a 135mm fan spinning on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.
All wrapped up | Protective PCB Coating
A protective conformal coating envelops the PCB to protect against short-circuits caused by moisture, dust, and debris.
Heart of gold | 80 Plus Gold Certification
The TUF Gaming 850W Gold Aura Edition features efficient, low-ESR Japanese capacitors to ensure efficient operation - affording it 80 PLUS® Gold status. This means it delivers up to 92% efficiency, resulting in less heat, reduced fan noise, and increased reliability
Step into the future | ATX 3.0 Compatible
The latest power specification updates have landed. ATX 3.0 ushers in tighter voltage and current regulation guidelines for next-gen hardware - and TUF Gaming 850W Gold steps ahead of the curve by being fully compliant. A 16-pin PCIe cable ripe for piping up to 600W of power to PCIe Gen 5.0 graphics cards is bundled with the PSU, bringing large-scale capabilities.
Better, faster, stronger | Axial-tech Fan Design
Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure. For TUF Gaming series PSUs, we've scaled that design to 135mm so it keeps things cool at low RPMs while producing less noise.
A decade of power | 10-Year Warranty
We're so confident about the reliability of the TUF Gaming 850W Gold that we back it with a 10-year worldwide warranty.
Supple ply | Fully Modular Etched Cables
The included fully-modular cable set is etched to provide a similar aesthetic to sleeved cables but a touch more flexibility for tight spaces.
- Warranty
- Limited Warranty
- 10 Year
- Technical Information
- Specification Compliance
- ATX 3.0
- ATX12V
- ATX 3.1
- Efficiency
- 92%
- Power Factor Correction (PFC)
- Active
- Number of Fans
- 1
- Fan Bearing Type
- Dual Ball Fan Bearing
- Fan Diameter
- 135 mm
- Protection Type
- Over Power
- Over Voltage
- Under Voltage
- Short Circuit
- Over Current
- Over Temperature
- Modular
- Yes
- Reliability
- MTBF
- 120000 Hour
- Power Description
- Number of +12V Rails
- 1
- Input Voltage
- 120 V AC
- 230 V AC
- Output Voltage
- 3.3 V DC
- 5 V DC
- 12 V DC
- -12 V DC
- 5 V SB
- Output Voltage Detail
- 3.3 V DC @ 25 A
- 5 V DC @ 25 A
- 12 V DC @ 70.8 A
- -12 V DC @ 0.8 A
- 5 V SB @ 3 A
- Output Power
- 850 W
- Interfaces/Ports
- Number of SATA Power Connectors
- 5
- PCI Express Connector
- Yes
- Number of (4+4 pin) CPU Power Connectors
- 2
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Physical Characteristics
- Form Factor
- ATX
- Height
- 150 mm
- Width
- 150 mm
- Depth
- 86 mm
- Weight (Approximate)
- 2.38 kg
- Miscellaneous
- Package Contents
- TUF Gaming 850W Power Supply
- 1 x Power Cord
- 1 x Motherboard Power Cable
- 2 x (610mm) CPU Cable
- 1 x (650mm) PCI-E Gen 5.1 16-pin Cable
- 1 x (675mm) PCI-E (16-pin to 8-pin-8-pin) Cable
- 1 x (675mm) PCI-E 1-to-1 Cable
- 1 x (675mm) SATA 1-to-2 Cable
- 1 x (400+120mm) SATA 1-to-3 Cable
- 1 x (400+120+120mm) Peripheral 1-to-4 Cable
- 3 x (400+150+150+150mm) TUF Gaming Cable Tie
- 1 x User Manual
- Energy Efficiency Certification
- 80 Plus Gold
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
